APC Back-UPS Pro Family BR1000G-CN 1000VA/600W Standby UPS with Built-in Battery

The APC Back-UPS Pro BR1000G-CN is a premium Standby UPS designed to deliver 1000VA/600W of highly reliable backup power. Engineered with a built-in heavy-duty battery and an advanced Automatic Voltage Regulation (AVR) system, it ensures your sensitive equipment operates safely under unstable low or high voltage conditions. Featuring comprehensive data line protection (10/100/1000 Mbps RJ-45 Ethernet and RJ-11 Telephone/Fax), 355 Joules of surge protection, and an ultra-high operating efficiency of over 98%, the BR1000G-CN is the ultimate uninterruptible power solution for high-end communication networks, smart offices, and critical lighting systems.

Key Functions and Features

High Efficiency & Robust Performance

High Efficiency: Achieves an outstanding operating efficiency of over 98%.

Clean Operation: The UPS itself does not generate additional input power factor or harmonic current distortion, ensuring zero interference to the main power grid.

Strong Output Capability: Optimized electrical performance with no strict limitations on load current crest factor, surge current factor, or moderate overloads.

Comprehensive System & Data Line Protection

Lightning & Surge Protection: Equipped with 355 Joules of surge energy rating to guarantee protection against surges, spikes, and lightning.

Data Line Protection: Built-in RJ-45 (10/100/1000 Mbps Ethernet) and RJ-11 (Telephone/Fax/Modem/DSL) interfaces protect your communication lines from backdoor surges.

Over-temperature Protection: Issues an over-temperature warning (LED light illuminates and a continuous beeping sound) if overheated. It automatically shuts down and disconnects the device if the temperature remains critical.

Manually Resettable Circuit Breaker: Easily restore the circuit from overload or open-circuit conditions with a push-button—no need to search for replacement fuses.

Advanced AVR & Intelligent Management

Automatic Voltage Regulation (AVR): Increases the output voltage when mains drop below a safe level, enabling equipment to operate safely without draining the battery.

Sensitivity Settings: Adjust the number of times the Back-UPS switches to battery power for devices with varying sensitivities to mains voltage fluctuations.

Personal Software Management: Supports power storage configuration, alarm settings, and monitoring of UPS power usage and events to protect your computer during outages.

Easy to Use & Maintain

Automatic Self-Test: Regularly tests the battery to ensure that aging batteries are detected early.

Audible Alarms: Informs you in advance about UPS battery replacement needs and power usage status.

External Battery Connector: A convenient pull-down handle facilitates safe connection and transportation.

Fast Switching Time: Output voltage switching time of approximately 10 milliseconds.

Technical Specifications (Back-UPS Pro Series)

Specifications	BR550G-CN	BR1000G-CN (Main Model)	BR1500G-CN
Output Capacity	550VA / 330W	1000VA / 600W	1500VA / 865W
Input Voltage Range	176V ~ 282V	176V ~ 294V	176V ~ 294V
Voltage Regulation (AVR)	188V-214V +11.2%	188V-216V +11.2%	188V-216V +11.2%
Input Frequency	50/60 Hz ± 3 Hz	50/60 Hz ± 3 Hz (Auto)	50/60 Hz ± 3 Hz
Output Frequency	50/60 Hz ± 3 Hz	50/60 Hz ± 3 Hz (Adj.)	50/60 Hz ± 3 Hz
Power Supply Waveform	Stepped Sine Wave	Stepped Sine Wave	Stepped Sine Wave
Surge Energy Rating	420 Joules	355 Joules	355 Joules
Data Line Protection	RJ-45 & RJ-11	RJ-45 (Gigabit) & RJ-11	RJ-45 & RJ-11
Typical Charging Time	12 Hours	8 Hours	8 Hours
Unit Dimensions (H×W×D)	190 × 90.9 × 309.9 mm	249.9 × 100.1 × 382 mm	302.3 × 111.8 × 381 mm
Unit Net Weight	2.96 kg	4.86 kg	6.05 kg
Transport Dimensions	252 × 137.9 × 442 mm	337.1 × 218.4 × 482.6 mm	381 × 228.6 × 482.6 mm
Transport Weight	3.49 kg	5.76 kg	6.25 kg

Wide Range of Applications

The BR1000G-CN is engineered to provide premium power protection for a variety of critical environments:

High-Speed Communication: Protects gigabit routers, modems, and network switches from both power outages and data line (RJ-45/RJ-11) surges.

Office & Computer Systems: Safeguards desktop PCs, monitors, and servers, preventing data loss and hardware damage.

Lighting & Smart Home: Provides seamless transition power for emergency classification lighting and sensitive home automation systems.

Our Factory

apc back ups family bk500m ch 500va/300w standby ups with built in battery

Our Certifcate

Exhibition

Packaging & Shipping

Frequently Asked Questions (FAQ)

Q1: Does the BR1000G-CN offer network and data line surge protection?

A: Yes, it features comprehensive data line protection, including 10/100/1000 Mbps Ethernet cable protection (RJ-45 interface) and Telephone/Fax/Modem/DSL analog line protection (RJ-11).

Q2: How does the Automatic Voltage Regulation (AVR) work on this model?

A: The built-in AVR automatically corrects low and high voltage conditions (between 176V and 294V) to safe levels without using the battery, ensuring your equipment operates smoothly while preserving battery life for actual power outages.

Q3: What is the typical charging time and surge energy rating?

A: The typical charging time for the BR1000G-CN is 8 hours. It is equipped with a robust surge energy rating of 355 Joules.

Q4: How do I handle battery replacement and after-sales service?

A: The product is covered by a standard 2-year warranty from the date of purchase. For safety and optimal performance, please contact authorized APC service centers for battery replacement and technical support.

Q5: What are the shipping specifications and the HS Code?

A: For large orders, the standard carton transport package dimensions are 34 x 48.5 x 23.5 cm with a gross weight of 12.73 kg (Basic Info configuration). The official export HS Code is 8504402000.
